Quectel M66 Industrial Grade 2G Module PCB

Product Description

Quectel M66 Industrial Grade 2G Module PCB, designed for high-performance applications in various industrial environments. Leveraging Quectel's ultra-compact and robust M66 GSM/GPRS module, this PCB is built for reliability and optimized connectivity. With a 5V DC input, the M66 PCB powers seamless data and SMS communication across diverse sectors, from automotive and telematics to smart metering and personal tracking. Designed to operate in demanding conditions, this module ensures robust connectivity for critical machine-to-machine (M2M) and IoT applications.

Product Highlights

• Compact and Reliable: Measuring just 17.7mm x 15.8mm x 2.3mm, the M66 module offers a compact LCC package, perfect for space-constrained applications while supporting mass-scale, cost-effective manufacturing.
• Quad-Band Connectivity: Supports GSM/GPRS across 850/900/1800/1900 MHz, providing reliable global communication options.
• Extended Temperature Range: Operates efficiently between -40C and 85C, suitable for challenging environments.
• Power-Efficient: Low power consumption (1.2 to 1.3 mA in idle mode), making it ideal for battery-powered applications.
• Advanced Data and Voice Features: Supports GPRS Class 12 with download/upload speeds up to 85.6 kbps, and SMS capabilities.

Key Specifications

• Data & Network:
  • GPRS Class 12, Quad-band GSM (850, 900, 1800, 1900 MHz)
  • Data rate: Up to 85.6 kbps for both download and upload
  • SMS (Text/PDU modes)
• Interfaces:
  • UART, Analog Audio, PCM, SIM card support
  • Supports TCP, UDP, FTP, HTTP, and SSL protocols
• Environmental & Power:
  • Power Supply: 3.3V to 4.6V with typical consumption of 1.3 mA (standby)
  • Operating temperature: -40C to +85C
  • High sensitivity for reliable signal reception in remote areas

·        Dimension: 65 mm X 34 mm

Applications

The Quectel M66 module's versatility makes it suitable for:

• Telematics and Asset Tracking: For real-time tracking and data transmission
• Industrial Automation and Monitoring: Connect sensors and machines in real-time
• Smart Metering: Streamlines data logging and reporting in utilities
• Point of Sale (POS) Terminals: Ideal for secure transaction processing
• Wearable Devices: Compact and lightweight for seamless integration

This industrial-grade 2G module is tailored for solutions requiring reliable 2G connectivity and extended performance under harsh conditions, making it ideal for M2M and IoT applications across multiple sectors.

For more technical details, refer to the Quectel M66 datasheet or contact us to discuss how this module can support your specific project needs‹
